技术参数 Technical Data

规格 Specification 项目 Item	FLP-Mini 台式Table model	FLP -0.5 台式Table model	FLP-1.5 台式Table model	FLP-3 台式/立式Table/Vertical model	FLP-5 台式/立式Table/Vertical model
生产能力Capacity (Kg /批 batch)	0.05-0.2	0.2-0.5	0.5-1.5	1-3	3-5
流体适用范围 Scope of application for liquid(g/cm3)	＜1.3
成品含水量 Water content of end products(%)	最高可达0.5 Max up to 0.5
容器容积 Container volume (L)	2.5-3	3-3.8	3-7	6-10	8-15
直径 Diameter(mm)	200	250	300	350	400
风机功率 Power of fan(Kw)	0.75	2.2	3	4	4
电加热 Power of electrical heater(Kw)	1.5	1.5	3	6	9
旋转电机功率 Power of rotating motor (Kw)		0.18	0.37	0.55	0.75
压缩空气压力Pressure of compressed air (Mpa)	0.4-0.6
压缩空气耗量Consumption of compressed air (m3/min)	0.2	0.3	0.35	0.6	0.4
作业温度 Working temperature(℃)	常温-100℃可调 Normal temperature -100℃ could adjust
产品主要尺寸(长×宽×高mm）Overall dimension of machine (L×W×H)	详见安装布局图 Pls refer to installation drawing for detailed information

所有数据仅作参考，视物料情况，本公司拥有变更权利，并不另行通知。
All datas are used for reference only. According to the condition of material, our factory has the right change but not notice, pardon
